Game Boy hardware database

DMG: G01898668 [gekkio]

Color
OffWhite
Assembly date
August/1989

Mainboard

Board type
DMG-CPU-02
Stamp on board
908-205
Extra label
1

LCD Board

Board type
DMG-LCD-01
Stamp
903-22
Circled letter(s) on board
Z
LCD panel label
N1 AH910720
LCD panel date
July/1991

Power Board

Board type
Type A2
Manufacture date
1989
Label
DC CONV DMG

Jack Board

Board type
DMG JACK 02

Chips

ChipTypeManufacturerDateLabel
U1CPUDMG-CPU ASharpWeek 29/1989DMG-CPU A © 1989 Nintendo JAPAN 8929 D
U2Video RAMLH5264N4SharpWeek 28/1989LH5264N4 SHARP JAPAN 8928 5 Y
U3Work RAMLH5264N4SharpWeek 28/1989LH5264N4 SHARP JAPAN 8928 5 Y
U4AmplifierIR3R40SharpWeek 26/1989DMG-AMP IR3R40 8926 A
X1Crystal4.194304 MHzDaishinkuMay/1989D419E9
-LCD Column DriverLH5077 AFSharpWeek 26/1991LH5077 AF 1260
-LCD Row DriverLH5076 AFSharpWeek 20/1991LH5076 AF 1200
-LCD RegulatorIR3E02SharpWeek 6/1989DMG-REG IR3E02 8906 A
